GRACO 96G291 - G3 Standard Oil Lubrication Pump, 100-240 VAC, 16L, Low Level Relay, DIN
The Graco G3 Standard is an electric automatic lubrication pump that delivers metered shots of lubricant to multiple points on a programmed schedule. With no onboard controller, it runs from your existing machine control or PLC for a low-cost way to automate lubrication.
Key Features
Specifications
| Series | G3 Standard |
| Lubricant | Oil (40 cSt minimum) |
| Reservoir Capacity | 16L |
| Input Voltage | 100-240 VAC |
| Reservoir Type | Standard |
| Low-Level Monitoring | Low-level relay output |
| Power Connector | DIN |
| Pump Elements | 1 adjustable element included (3 maximum) |
| System Compatibility | Injector-based and series progressive |
| Graco Model Code | A-ACNC-160A00-LD000000 |
Installation Notes
A pressure relief valve (Graco 16C807) is required at each pump outlet and is sold separately. Mount the pump upright.
GRACO 96G291 - G3 Standard Oil Lubrication Pump, 100-240 VAC, 16L, Low Level Relay, DIN
The Graco G3 Standard is an electric automatic lubrication pump that delivers metered shots of lubricant to multiple points on a programmed schedule. With no onboard controller, it runs from your existing machine control or PLC for a low-cost way to automate lubrication.
Key Features
Specifications
| Series | G3 Standard |
| Lubricant | Oil (40 cSt minimum) |
| Reservoir Capacity | 16L |
| Input Voltage | 100-240 VAC |
| Reservoir Type | Standard |
| Low-Level Monitoring | Low-level relay output |
| Power Connector | DIN |
| Pump Elements | 1 adjustable element included (3 maximum) |
| System Compatibility | Injector-based and series progressive |
| Graco Model Code | A-ACNC-160A00-LD000000 |
Installation Notes
A pressure relief valve (Graco 16C807) is required at each pump outlet and is sold separately. Mount the pump upright.
