Item #: JC40L9
Price: $14,057.14
Call 888-654-8898
Need this Product for a Specific Application?
Use our handy finder to find the exact model for your needs.
GRACO JC40L9 High-Flo 4-Ball Pump, CS, 4:1, Low Noise Exhaust, Open Wet Cup Lower, NPT Fittings, Ultralife Rod/Cylinder
Pneumatic High-Flo 4-ball piston pumps provide high output per cycle to reduce pump wear and maintenance. Ideal for low pressure, high flow applications and inherently safe for hazardous locations.
Specifications:
| Application | Circulation |
| Compatible Material | Waterborne, Solventborne, High Solids, Xirallic, Metallics, Topcoats, Stains, Varnish, CARC |
| Fluid Outlet Size (in) | 1-1/2 |
| Fluid Outlet Thread Type | NPT |
| Fluid Section Type | Open Wet Cup |
| Includes | Carbon Steel Pump, Low Noise Exhaust, NPT Fittings, Ultralife Rods, Ultralife Cylinder |
| Material | Carbon Steel |
| Maximum Air Inlet Pressure (psi) | 100 |
| Maximum Continuous Cycle Rate (CPM) | 12 |
| Maximum Flow Rate (GPM) | 16.9 |
| Maximum Operating Temperature (°F) | 150 |
| Maximum Working Pressure (MPa) | 3.1 |
| Maximum Working Pressure (psi) | 450 |
| Motor Type | Low Noise NXT |
| Portable | Non-Portable |
| Pump Ratio | 4:1 |
| Standards Met | ATEX, CE |
| Type | Pneumatic Piston Pump |
| Wetted Material | Carbon Steel |
GRACO JC40L9 High-Flo 4-Ball Pump, CS, 4:1, Low Noise Exhaust, Open Wet Cup Lower, NPT Fittings, Ultralife Rod/Cylinder
Pneumatic High-Flo 4-ball piston pumps provide high output per cycle to reduce pump wear and maintenance. Ideal for low pressure, high flow applications and inherently safe for hazardous locations.
Specifications:
| Application | Circulation |
| Compatible Material | Waterborne, Solventborne, High Solids, Xirallic, Metallics, Topcoats, Stains, Varnish, CARC |
| Fluid Outlet Size (in) | 1-1/2 |
| Fluid Outlet Thread Type | NPT |
| Fluid Section Type | Open Wet Cup |
| Includes | Carbon Steel Pump, Low Noise Exhaust, NPT Fittings, Ultralife Rods, Ultralife Cylinder |
| Material | Carbon Steel |
| Maximum Air Inlet Pressure (psi) | 100 |
| Maximum Continuous Cycle Rate (CPM) | 12 |
| Maximum Flow Rate (GPM) | 16.9 |
| Maximum Operating Temperature (°F) | 150 |
| Maximum Working Pressure (MPa) | 3.1 |
| Maximum Working Pressure (psi) | 450 |
| Motor Type | Low Noise NXT |
| Portable | Non-Portable |
| Pump Ratio | 4:1 |
| Standards Met | ATEX, CE |
| Type | Pneumatic Piston Pump |
| Wetted Material | Carbon Steel |
