Item #: 28076T10/32-MIDLAND
Price: $1.40
Call 888-654-8898
Need this Product for a Specific Application?
Use our handy finder to find the exact model for your needs.
Midland Industries 28076T10/32 Pipe Cap w/ 10-32 UNF Holes, 1/4" NPTF, 0.6" Brass
| SKU: 28076T10/32 | |
|---|---|
| Connection Size 1 | 1/4 in |
| Connection Type | NPT |
| Connection Type 1 | NPTF |
| Fitting Type | Cap |
| For Use With | Aluminum, Brass, Bronze, Copper, Iron and Steel Pipe |
| Hex Size | 0.68 in |
| Length | 0.6 in |
| Material | Brass |
| Material Construction | Brass |
| Pressure Rating | 1200 psi |
| Temperature Rating | -65 to 250 deg F |
| Thread Size | 1/4-18 |
| Typical Application: | Grease, fuels, LP and Natural gas (available on special order), refrigeration, instrumentation & hydraulic systems. |
| Pressure | Operating pressure up to 1200 PSI. |
| Vibration | Fair resistance. |
| Temperature Range | -650F to +2500F |
| Used With | Brass, bronze, copper, steel, aluminum and iron pipe. |
| Tolerance | +/- .02 on all dimensions. |
| Approvals | Meets functional requirements of SAE J530, J531 |
| Not Lead Free | |
"L" at the end of a Part# means Light Pattern - these fittings are completely interchangeable with full pattern fittings, but have been modified in some way. This modification is usually in the length of the pipe threads. Used in plumbing and light industrial applications.
Assembly Instructions:
Midland Industries 28076T10/32 Pipe Cap w/ 10-32 UNF Holes, 1/4" NPTF, 0.6" Brass
| SKU: 28076T10/32 | |
|---|---|
| Connection Size 1 | 1/4 in |
| Connection Type | NPT |
| Connection Type 1 | NPTF |
| Fitting Type | Cap |
| For Use With | Aluminum, Brass, Bronze, Copper, Iron and Steel Pipe |
| Hex Size | 0.68 in |
| Length | 0.6 in |
| Material | Brass |
| Material Construction | Brass |
| Pressure Rating | 1200 psi |
| Temperature Rating | -65 to 250 deg F |
| Thread Size | 1/4-18 |
| Typical Application: | Grease, fuels, LP and Natural gas (available on special order), refrigeration, instrumentation & hydraulic systems. |
| Pressure | Operating pressure up to 1200 PSI. |
| Vibration | Fair resistance. |
| Temperature Range | -650F to +2500F |
| Used With | Brass, bronze, copper, steel, aluminum and iron pipe. |
| Tolerance | +/- .02 on all dimensions. |
| Approvals | Meets functional requirements of SAE J530, J531 |
| Not Lead Free | |
"L" at the end of a Part# means Light Pattern - these fittings are completely interchangeable with full pattern fittings, but have been modified in some way. This modification is usually in the length of the pipe threads. Used in plumbing and light industrial applications.
Assembly Instructions:
