Reelcraft B3425-OLP - 1/4" x 25 ft. Compact Air/Water Hose Reel
Reelcraft’s new Series 3000 reels are all-steel construction and ultra-compact for a wide range of bench mount or mobile applications with critical space requirements.
- Compact size – reel easily fits within a 1 ft. x 1 ft. space
- Multiple slotted mounting holes to accommodate many configurations
- An optional guide arm accessory is available for multiple adjustment positions of the hose.
- All steel components are individually powder coated to virtually eliminate corrosion.
Weight | 18 lbs |
Series | 3000 |
Hose I.D. | 1/4" |
Hose O.D. | 0.475" |
Hose Length | 25' |
Pressure | 300 psi |
Hose End | 1/4" NPT(M) |
Inlet | 3/8" NPT(F) |
Reel Outlet | 3/8" NPT(F) |
Hose Included | Yes |
Max Temperature | 150 °F |
UPC | 699567025344 |
Internal Fluid Path | Steel |
Swivel Assembly | Copper |
Swivel Seal | Buna |
