Reelcraft C23012-H - 12" Versatile Aluminum Spray Reel, 4500 psi, Gray Poly-Coating

Reelcraft C23012-H - 12" Versatile Aluminum Spray Reel, 4500 psi, Gray Poly-Coating

Reelcraft C23012-H - 12" Versatile Aluminum Spray Reel, 4500 psi, Gray Poly-Coating

Reelcraft C23012-H - 12" Versatile Aluminum Spray Reel, 4500 psi, Gray Poly-Coating

Item #: C23012-H

MSRP: Price: $711.26

Price: with strikethrough $711.26

Retail Price:

Sale Price: Price $660.46

(You save $50.80 )

Most orders over $299
ship for free | See Details

Have a Question?
ASK NATE

Get Expert Advice or

Call 888-654-8898

Get Expert Advice or

Call 888-654-8898

Need this Product for a Specific Application?

Use our handy finder to find the exact model for your needs.

FIND MY PRODUCT

Essential Accessories

Item Description

C23012 H – Heavy Duty Aluminum Hand Crank Hose Reel

Features:

Aluminum construction is 50% lighter in weight than carbon steel and corrosion resistant.
The baked-on, polyester powder-coat finish protects against salt spray and rated for up to 20% bleach solution.
Hardware includes a two-coat plating process that resists salt spray and acids.
3/4″ fluid path constructed of 316 stainless steel is designed to handle harsh chemicals. This model includes a carbon steel swivel rated to 4500 PSI.
Includes spring loaded latching mechanism and drag brake to control over spooling.
Innovative design allows for the handle or swivel to be easily swapped from one side to the other.
Drive type – hand crank rewind
Hose not included
Made in the USA

Specifications:

Weight	23 lbs
Series	20000
3/8" Hose Capacity	300'
1/2" Hose Capacity	200'
5/8" Hose Capacity	150'
3/4" Hose Capacity	125'
Pressure	4500 psi
Inlet	3/4" NPT(F)
Reel Outlet	3/4" NPT(F)
Hose Included	No
Max Temperature	210 °F
UPC	699567031765
Carton Dimensions	24" x 18" x 18"
Internal Fluid Path	Stainless Steel
Swivel Assembly	Carbon Steel
Swivel Seal	FKM

C23012 H – Heavy Duty Aluminum Hand Crank Hose Reel

Features:

Aluminum construction is 50% lighter in weight than carbon steel and corrosion resistant.
The baked-on, polyester powder-coat finish protects against salt spray and rated for up to 20% bleach solution.
Hardware includes a two-coat plating process that resists salt spray and acids.
3/4″ fluid path constructed of 316 stainless steel is designed to handle harsh chemicals. This model includes a carbon steel swivel rated to 4500 PSI.
Includes spring loaded latching mechanism and drag brake to control over spooling.
Innovative design allows for the handle or swivel to be easily swapped from one side to the other.
Drive type – hand crank rewind
Hose not included
Made in the USA

Specifications:

Weight	23 lbs
Series	20000
3/8" Hose Capacity	300'
1/2" Hose Capacity	200'
5/8" Hose Capacity	150'
3/4" Hose Capacity	125'
Pressure	4500 psi
Inlet	3/4" NPT(F)
Reel Outlet	3/4" NPT(F)
Hose Included	No
Max Temperature	210 °F
UPC	699567031765
Carton Dimensions	24" x 18" x 18"
Internal Fluid Path	Stainless Steel
Swivel Assembly	Carbon Steel
Swivel Seal	FKM
