Reelcraft FF9600-OLPBW 1-1/2 x 50ft, 600 psi, Fuel Without Hose
Reelcraft's spring retractable fuel delivery reels, equipped with Viton seals, incorporate metal forms to insure the greatest possible strength and are ideal for mobile and permanent-mount applications. These rugged, corrosion-resistant reels are suitable for a wide variety of fuel applications including E85.
Features:
- Substantial base frame – The full width frame has the greatest amount of mounting area and overall strength of reels within its class.
- Full flow stress free swivel design – The full flow swivel combines the highest grade seal design and materials with bearing areas to insure maximum service life.
- Quality finish and corrosion resistant – Individually powder coated components offer the maximum protection from premature corrosion.
Specifications:
Weight | 135 lbs |
Series | F9000 |
Hose I.D. | 1 1/2" |
Hose O.D. | 2.000" |
Hose Length | 50' |
Pressure | 600 psi |
Inlet | 1 1/2" NPT(F) |
Reel Outlet | 1 1/2" NPT(F) |
Hose Included | No |
Max Temperature | 210 °F |
UPC | 699567001560 |
