Reelcraft FHD79035 OLP - 3/4" x 35 ft. Heavy Duty Fuel Hose Reel
Reelcraft’s spring retractable Series HD70000 fuel delivery hose reels, equipped with Viton seals, incorporate metal forms and a heavy-duty base to ensure the greatest possible strength and are ideal for mobile and permanent-mount applications. These rugged, corrosion-resistant reels are suitable for a wide variety of fuel applications including E85. Series F7000 reels are supplied with our ball-bearing style swivel.
- Compact design - Reels are 25% smaller than our heavy-duty Series 80000 reels.
- Guide rollers - The one-piece design and stainless steel pins offer greater strength and easier serviceability.
- Ease of operation - The high quality, die-cast aluminum hub, and two sealed ball bearings produce a smoother spool rotation and easier operation.
- Full flow stress free swivel design - The full flow swivel combines the highest grade seal design and materials with bearing areas to insure maximum service life.
*Reel is shipped in the top wind position. The reel image is shown in the side wind position.
Specifications:
Weight | 79 lbs |
Series | HD70000 |
Hose I.D. | 3/4" |
Hose O.D. | 1.188" |
Hose Length | 35' |
Pressure | 50 psi |
Hose End | 3/4" NPT(M) |
Inlet | 3/4" NPT(F) |
Reel Outlet | 3/4" NPT(F) |
Hose Included | Yes |
Max Temperature | 150 °F |
UPC | 699567027065 |
