Reelcraft HD78005 OLB – 1/2 in. x 75 ft. Heavy Duty Hose Reel w/ Stainless Fluid Path
Reelcraft offers a chemical resistant fluid path as an option for our most popular models series. The reels include a Stainless Steel path and swivel (components in contact with the fluid) that provide maximum protection for corrosive fluid applications.
FKM swivel seals included on this model
- Stainless steel fluid path and swivel provide maximum protection for corrosive fluid applications
- Redesigned latching mechanism provides longer service life for the latch components
- Guide rollers – The one-piece design and stainless steel pins offer greater strength and easier serviceability
- Containerized drive spring offers easier handling during maintenance
- Hose not included on this model
- Base plate and upright are constructed from 7 gauge steel; the guide arm is 11 gauge and the spool is 16 gauge steel
- Guide arm adjusts to seven positions
- Ease of operation – The high-quality, die-cast aluminum hub, and two sealed ball bearings produce a smoother spool rotation and easier operation.
- Made in the USA
*Reel is shipped in the top wind position. The reel image is shown in side wind position.
Specifications:
Weight |
54 lbs |
Series |
HD70000 |
Hose I.D. |
1/2" |
Hose O.D. |
0.75" |
Hose Length |
75' |
Pressure |
500 psi |
Inlet |
1/2" NPT(F) |
Reel Outlet |
1/2" NPT(F) |
Hose Included |
No |
Max Temperature |
210 °F |
UPC |
699567027478 |
