Safewaze 022-4086 Reach Anchor

Item #: 022-4086

Price: $1,090.00

QTY:

Most orders over $299
ship for free | See Details

Have a Question?
ASK NATE

Get Expert Advice or

Call 888-654-8898

Get Expert Advice or

Call 888-654-8898

Need this Product for a Specific Application?

Use our handy finder to find the exact model for your needs.

FIND MY PRODUCT

Related Items

Item Description

Safewaze 022-4086 - Reach Anchor

The Reach Anchor is a proprietary anchor for workers to remotely anchor to an elevated point, increasing safety for the first workers needing anchorage in a given at-height situation. It's compact, lightweight fall protection in two simple steps: the versatile Reach Anchor connects first, without the added weight of an SRL, then the SRL can be easily raised and secured.

Key Features

Proprietary system to remotely anchor to an elevated point
Connects to I-beams up to 12”, pipes and other pre-established anchor points
Compact, lightweight, and portable
Remote release using telescoping pole (not included) and attachments
Easy 2-stage installation to attach anchor point and raise PFAS
Prevent accidental disengagement with safety toggle on self-tightening jaws
Corrosion-resistant premium grade aluminum components add strength
Includes (1) Magnetic Quick Connector Base and (1) Hook Attachment
Does not include extension pole

Specifications

Product Specification 1	Maximum Install Height: 20 ft. from working surface
Product Specification 2	Working Load Limit: 1,000 lbs. (4.4 kN)
Product Specification 3	I-Beam Size: Up to 12 in.
Materials	Aluminum, stainless steel, steel, nylon, polyester rope
Dimensions	27.2 in. x 8.9 in. x 6.3 in. (690mm x 225mm x 160mm)
Attachment Points	D-ring
Minimum Breaking Strength	5,000 lbs. (22kN)
ANSI Weight Capacity	130-310 lbs. (59-141 kg)
OSHA Weight Capacity	Up to 420 lbs. (191 kg)
ANSI Standards	Z359.18-2017 Type A
OSHA Standards	1926.502, 1910.140, 1910.66
