Safewaze 023-12154 10' to 20' Belmont Safety Hatch System with Flat Brackets
The 10' to 20' Belmont Safety Hatch System with Flat Brackets is a complete solution for safe rooftop access when using a hatch from a fixed ladder. Open, close and secure the roof hatch from the safety of the ground, leaving hands free for climbing. An innovative built-in pole extends at top to ensure smooth transitions between the ladder and roof.
Features:
- System mounts directly to ladder for stability Ground level operation to open, close and secure hatch Safe transitions with built-in extension pole Manually operated drive unit with simple crank Installs on systems from 10' to 20'
- For use on hatches from 30" square to 36" square Assembly required, padlock not included Includes all required components and fasteners:
- - (6) Brackets for side mounted installation on flat bar stock (max. 4")
- - (1) Lifting tube extension
- - (2) Intermediate guide brackets
- - (1) Drill bit rivet adapter
Specifications:
Materials | Powder coated steel, zinc plated steel fasteners |
Weight | 41.0 lbs. (18.6 kg) |
System Length | 10' to 20' (3.0 m to 6.1 m) |
System Capacity | 600 lbs. (272.2 kg) |
ANSI Standards | N/A |
OSHA Standards | N/A |
