GRACO 26C793 - XHF Top Feed Airless Spray Gun, XHDRAC Tip, 7250 PSI
XHF Gun Top Feed designed for the heaviest coatings and fibrous materials. Features oversized fluid passages and filterless design for maximum flow and superior atomization. Built for high-viscosity, protective coatings including epoxy, intumescent coatings and fiber filled materials.
Features:
Designed to spray high viscosity materials, the XHF Top Feed Gun is rugged, reliable and easy to maintain.
For epoxy intumescent fireproofing coatings
- High-flow, high pressure gun
- Handles epoxy intumescent materials, high-viscosity coatings, fiber filled materials
- Top fed fluid inlet allows sub grade work to be done with ease.
Additional Specifications
- Max Working Pressure: 7250 PSI (500 bar)
- Feed Type: Top Feed
| Applicator Type | Manual |
| Compatible Material | Epoxy Intumescent Fireproofing |
| Fluid Inlet Size (in) | 3/8 |
| Fluid Inlet Thread Gender | Male |
| Fluid Inlet Thread Type | NPT |
| Fluid Orifice Size (in) | 0.125 |
| For Use With | Protective Coating High-Pressure Equipment |
| Gun Activation | Manual |
| Gun Included | 1 |
| Gun Type | Airless Gun |
| Gun Weight (lb) | 1.6 |
| Gun Weight (oz) | 26 |
| Includes | XHD RAC Guard, XHD429 SwitchTip |
| Maximum Fluid Pressure (MPa) | 50 |
| Maximum Fluid Pressure (psi) | 7250 |
| Maximum Fluid Working Pressure (MPa) | 50 |
| Maximum Fluid Working Pressure (psi) | 7250 |
| Overall Height (in) | 7.0 |
| Overall Length (in) | 8.25 |
| Product Type | Spray Gun |
| Purge Method | Liquid |
| Sound Power Level (dB(A)) | 93 |
| Sound Pressure Level (dB(A)) | 84 |
| Spray Pattern | Flat |
| Trigger Lock | Locking |
| Trigger Type | Full-Hand |
| Type | Spray Gun |
| Wetted Parts | Tungsten Carbide, 17-4PH Passivated Stainless Steel, Polypropylene, Polyethylene |
Features
- Oversized fluid path for no-filter design
- Maximum flow and superior atomization
- Patented needle design - factory set for adjustment-free operation
- Heavy-duty design for maximum performance and long life
- Ergonomic form-fitting handle for maximum control
- Optimized trigger and lightweight design for effortless all-day spraying
Applications
- Heaviest coatings and fibrous materials
- High viscosity protective coatings
- Epoxy intumescent coatings
- Fiber filled materials
- High-viscosity protective coatings
- Epoxy coatings
Compatible Equipment
- XHF gun systems
- High pressure airless spray equipment up to 7250 PSI
Related Parts
- 26C854 - XHF Gun with XHD 429 Tip
- 237260 - Repair Kit (XHF Gun)
- 26C854 - XHF Gun includes XHI 429 Tip
- 273260 - Repair Kit (XHF Gun)
- 26C824 - XHF Gun includes XHD 429 Tip
- 273500 - Repair Kit (XHF Gun)
Kit Contents
- 26C793 - XHF Gun Top Feed with XHD 429 Tip
- XHI 429 Tip included
- XHF Gun with tip feed configuration
- XHD 429 Tip
Top feed configuration includes XHD 429 tip. Part of XHF High-Flo gun family designed specifically for maximum flow applications. Part of the XHF HIGH-FLO series designed for maximum flow applications with heavy coatings Tip feed configuration allows for easy tip changes and maintenance. Designed specifically for the most demanding protective coating applications.
