GRACO 236144 - 10 Gal. Low Pressure HVLP Pot, Regulated to 15 PSI, ASME Rated, 33.9", 76 lbs, SST
GRACO lightweight aluminum pressure pot ideal for small batches, special color applications or infrequent production. Features pressure relief valve, convenient fluid outlet location and quick lock clamps. Provides accurate pressure control especially at low pressures with liners available for quick color changes and easy clean-up.
Designed with electroplated surfaces thatprevent debris build-up and keep youroperation free of contaminants, Gracopressure pots are precision welded andsurfaced.
- ASME rated to ensure it meets factory standards
- High quality stainless steel design is compatible with many materials
- Use in stand-alone spraying, material/catalyst supply, or as a moisture sensitive material reservoir
Additional Specifications
- Max Working Pressure: Low Pressure Regulated to 1.05 bar (15 PSI, 0.105 MPa)
- Material: High quality stainless steel
- Capacity: 10 Gallon (38 liter)
- Height: 33.9 in (88.0 cm)
- Weight: 76 lb (35 kg)
- Certification: ASME rated
- Agitators: No agitators
- Tank Size: 10 gallons (38 liters)
- Series: Series B
- Ce Approved: Category II Pressure Equipment Directive
| Inlet Size (in) | 1/4 |
| Inlet Thread Gender | Male |
| Inlet Thread Type | NPT |
| Maximum Volume Capacity (gal) | 10 |
| Maximum Working Pressure (MPa) | 0.1 |
| Maximum Working Pressure (psi) | 15 |
| Outlet Size (in) | 3/8 |
| Outlet Thread Gender | Male |
| Outlet Thread Type | NPSM |
| Overall Height (in) | 33.87 |
| Overall Width (in) | 19 |
| Type | Tank |
| Weight (lb) | 76 |
| Wetted Material | Stainless Steel, Santoprene, Polyamide, PET |
Features
- ASME rated to ensure it meets factory standards
- High quality stainless steel design compatible with many materials
- Low pressure regulation to 1.05 bar (15 PSI)
- No agitator model for simpler applications
- Lightweight aluminum construction
- Pressure relief valve
Applications
- Stand-alone spraying
- Material/catalyst supply
- Moisture sensitive material reservoir
- Small batches
- Special color applications
- Infrequent or build to order production
Compatible Equipment
- Spray adhesive systems
- HVLP spray systems
Related Parts
Model without agitators. Optional Gun Air Regulator Kit (235042) can be added. All pressure tanks with agitators feature heavy-duty back-geared models. Part of GRACO's pressure pot fluid supply system for spray applications. This is the model without agitators in the low pressure HVLP configuration. CE approved to the Pressure Equipment Directive (Category II). Part of a family of low-pressure and high-pressure tanks available in 5, 10, and 15 gallon sizes, with and without agitator options.
