GRACO 255249 - SST 2K Dispense Valve Lever, 3000 PSI (276 Bar, 27.6 MPa)

Electric lever handle for manual dispense operations, providing ergonomic control for fluid dispensing applications

Specifications

• Max Working Pressure: 3000 psi (276 bar, 27.6 MPa)
• Material: stainless steel, carbide, UHMWPE, acetal, PEEK, PTFE
• Maximum Cylinder Air Pressure: 120 psi (8.4 bar, 0.84 MPa)
• Minimum Air Cylinder Actuating Pressure: 40 psi (2.8 bar, 0.3 MPa)
• Maximum Working Fluid Temperature: 140°F (60°C)
• Fluid Inlets: 9/16-18 UNF (h 6G SAE)
• Air Inlets: 1/8 in NPT
• Voltage: 0.5 @ 28 VDC
• Torque Spec: 25 in-lb (2.8 N•m) for certain fasteners

Features

• Electric lever operation
• Manual dispense control
• Ergonomic operation
• High pressure capability

Applications

• Manual fluid dispensing
• Precision material application
• Industrial coating operations

Compatible Equipment

• MD2 dispense valves
• HFR manual 340237
• PR70 manual 334135
• AOP manual 332452

Related Parts

• 255208 - Handle Electric
• 255206 - Handle Pneumatic
• 255273 - Hanger adapter
• 24W045 - 25° angle adapter kit
• 24W046 - 15° angle adapter kit
• 24W047 - 5° angle adapter kit
• 255206 - Handle, 120 Psig (0.84 MPa, 8.4 Bar)
• 15K922

Part of the MD2 dispense valve system with angled adapter options available for more comfortable dispensing angles Listed under MD2 Valve Handles section. Related to other MD2 valve handle options including air trigger (255206) and electric air actuated (255208). This appears to be an assembly part number. The page shows an exploded view diagram with related component parts listed in the table. Assembly includes mounting block, bolts, nuts, washers, pivot pin, screws, plunger, lever, and trigger cable kit.

Reference Manuals

• 339117 (Page 3) MD2 Dispense valve
• 312185 (Page 3) MD2 Valve
• 312760 (Page 65) PR70 and PR70v, Repair
• 334135 (Page 11) PR70E
• 3A0237 (Page 10) Heated Hoses and Applicator Kits
