Item #: 236143
Price: $3,140.00
Call 888-654-8898
Need this Product for a Specific Application?
Use our handy finder to find the exact model for your needs.
GRACO 236143 - 5 Gal. Low Pressure HVLP Pot, 15 PSI, ASME Rated, 30.5" , 65 lbs, Stainless
GRACO 5-gallon low pressure HVLP pressure pot designed for spray adhesive applications. Features lightweight aluminum construction with portability in mind, equipped with pressure relief valve and convenient fluid outlet location with quick lock clamps. Ideal for small batches, special color applications, and infrequent or build-to-order production with accurate pressure control especially at low pressures.
Designed with electroplated surfaces that prevent debris build-up and keep your operation free of contaminants, Graco pressure pots are precision welded and surfaced.Additional Specifications
| Inlet Size (in) | 1/4 |
| Inlet Thread Gender | Male |
| Inlet Thread Type | NPT |
| Maximum Volume Capacity (gal) | 5 |
| Maximum Working Pressure (MPa) | 0.1 |
| Maximum Working Pressure (psi) | 15 |
| Outlet Size (in) | 3/8 |
| Outlet Thread Gender | Male |
| Outlet Thread Type | NPSM |
| Overall Height (in) | 30.5 |
| Overall Width (in) | 19 |
| Type | Tank |
| Weight (lb) | 65 |
| Wetted Material | Stainless Steel, Santoprene, Polyamide, PET |
Features
Applications
Related Parts
New optional Gun Air Regulator Kit (235042) can be added. All 19, 38, 57 (5, 10 and 15 gal) pressure tanks with agitators feature heavy-duty back-geared models. Instruction manual 306369. This is a pressure pot without agitators. Other capacities and configurations available in the same product family with varying pressure ratings and agitator options. All pressure tanks listed are CE approved to the Pressure Equipment Directive (Category II). This is a low-pressure stainless steel tank without agitator.
Reference Manuals
GRACO 236143 - 5 Gal. Low Pressure HVLP Pot, 15 PSI, ASME Rated, 30.5" , 65 lbs, Stainless
GRACO 5-gallon low pressure HVLP pressure pot designed for spray adhesive applications. Features lightweight aluminum construction with portability in mind, equipped with pressure relief valve and convenient fluid outlet location with quick lock clamps. Ideal for small batches, special color applications, and infrequent or build-to-order production with accurate pressure control especially at low pressures.
Designed with electroplated surfaces that prevent debris build-up and keep your operation free of contaminants, Graco pressure pots are precision welded and surfaced.Additional Specifications
| Inlet Size (in) | 1/4 |
| Inlet Thread Gender | Male |
| Inlet Thread Type | NPT |
| Maximum Volume Capacity (gal) | 5 |
| Maximum Working Pressure (MPa) | 0.1 |
| Maximum Working Pressure (psi) | 15 |
| Outlet Size (in) | 3/8 |
| Outlet Thread Gender | Male |
| Outlet Thread Type | NPSM |
| Overall Height (in) | 30.5 |
| Overall Width (in) | 19 |
| Type | Tank |
| Weight (lb) | 65 |
| Wetted Material | Stainless Steel, Santoprene, Polyamide, PET |
Features
Applications
Related Parts
New optional Gun Air Regulator Kit (235042) can be added. All 19, 38, 57 (5, 10 and 15 gal) pressure tanks with agitators feature heavy-duty back-geared models. Instruction manual 306369. This is a pressure pot without agitators. Other capacities and configurations available in the same product family with varying pressure ratings and agitator options. All pressure tanks listed are CE approved to the Pressure Equipment Directive (Category II). This is a low-pressure stainless steel tank without agitator.
Reference Manuals
