GRACO 236149 - 5 Gal. High Pressure HVLP Pot, Regulated to 100 PSI, ASME Rated, 30.5", 65 lbs, SST
High pressure HVLP pressure pot designed for spray adhesive applications, delivering superior atomization and consistent spray patterns. Features lightweight aluminum construction with portability design, pressure relief valve for safety, and convenient fluid outlet location with quick lock clamps. Ideal for small batches, special color applications, and infrequent production runs.
Designed with electroplated surfaces thatprevent debris build-up and keep youroperation free of contaminants, Gracopressure pots are precision welded andsurfaced.Additional Specifications
| Inlet Size (in) | 1/4 |
| Inlet Thread Gender | Male |
| Inlet Thread Type | NPT |
| Maximum Volume Capacity (gal) | 5 |
| Maximum Working Pressure (MPa) | 0.7 |
| Maximum Working Pressure (psi) | 100 |
| Outlet Size (in) | 3/8 |
| Outlet Thread Gender | Male |
| Outlet Thread Type | NPSM |
| Overall Height (in) | 30.5 |
| Overall Width (in) | 19 |
| Type | Tank |
| Weight (lb) | 65 |
| Wetted Material | Stainless Steel, Santoprene, Polyamide, PET |
Features
Applications
Compatible Equipment
Related Parts
New optional Gun Air Regulator Kit (235042) can be added to all tanks. Part of 19 liter (5 gallon) pressure pot family with various pressure regulation options. Instruction manual 306369 available. This is a high pressure model without agitators, part of GRACO's pressure pot line for spray adhesive applications. Works by placing fluid into vessel and pressurizing with air to create flow. This is the 5-gallon model without agitator in GRACO's pressure pot family for road striping applications
