GRACO 24C414 - Kit, Accessory, Ball Valve
Ball valve kit designed for FreeFlo and pole gun applications in the T-Max texture spraying system, providing reliable flow control and shutoff functionality for professional texture spraying operations
Description
The GRACO 24C414 Ball Valve Accessory Kit adds an in-line material shutoff at the gun to reduce drips during nozzle changes & short pauses. Designed for texture & coating applications, it’s a simple, durable way to control flow at the point of application. Use as an on/off shutoff only—do not throttle under pressure. Always depressurize before closing & fully open the valve before restarting flow.
- In-line shutoff to minimize leaks & mess during changeovers
- For FreeFlo inline guns & pole/extension applicators
- Rugged construction for jobsite use
- Quick, ergonomic handle operation
- Not a metering/throttling valve—on/off use only
Additional Specifications
| Brand | GRACO |
| Model | 24C414 |
| Series | Series A |
| Max Working Pressure | 1000 PSI (6.9 MPa, 69 bar) |
| Intended Use | Material shutoff at gun during pauses & nozzle changes |
| Compatibility | FreeFlo inline guns & pole/extension applicators |
| Use Guidance | Depressurize before closing; fully open before restarting; do not throttle |
Features
- Ball valve design for reliable flow control
- Kit format for easy installation and maintenance
- Compatible with FreeFlo and pole gun systems
Applications
- Texture spraying applications
- Professional spray finishing
- FreeFlo gun operations
- Pole gun applications
Compatible Equipment
- FreeFlo guns
- T-Max texture spraying systems
- select texture applicators
- 24B944 - Texture Applicator Pole for Airlessco TexSpray Texture Spray Guns
- 24B945
Related Parts
- 17Z910 - STX air assist texture trigger gun
- 17Z128 - FreeFlo inline gun
- 24S944 - Rigid pole gun 1m
- 24B945 - Flex head pole gun
- 17Z054 - T-Max lance with airless tips
- 17Y907 - Inline gun, RAC X
- HDA551
- 313537 - Free Flow Applicator
- 313895 - Flex Head and Pole Applicators
- 313896 - Flex Head and Pole Applicators
- 313897 - Flex Head and Pole Applicators
Part of the T-Max applicator family for professional texture spraying equipment Ball valve may be added to select texture applicators to control fluid leakage during nozzle changes and other temporary stoppages. Valve is NOT intended to shut off, control, or throttle fluid flow when system is pressurized. Ball valve must be opened prior to restarting machine. Thread sealant included in kit. This is an accessory ball valve kit that can be installed on certain texture applicators to stop product flow during nozzle changes or other temporary stops. The valve must be fully open before starting the sprayer and the system must be depressurized when the valve is closed.
Reference Manuals
- 320596 (Page 7) TEXSPRAY T-MAX™
- 313944 (Page 1) Ball Valve Accessory Kit, Kit Instructions
